Our company not only sells better quality bimetal thermostat, Refrigerator Fan Motor Suitable, WHIRLPOOL Refrigerator Door Switch China than our competitors, but also cheaper prices. The development of the enterprise relies on the diligence and wisdom of the operators, the support of the government at all levels and the sincere cooperation of friends from all walks of life, and the return is the greater contribution of the enterprise to society. Our success today is because we always adhere to the concept of integrity, with a number of years of customers and we grow together. We believe that difficulties and setbacks are always temporary, and as long as we work hard, there are always more solutions than problems. We have unswervingly implemented the five major competitive strategies, core technology leadership strategy, total cost leadership strategy, differentiation strategy, goal aggregation strategy and internationalization strategy.
High durability No breakdown, no flashover.
Every product will be tested with, extremely high-temperature pass rate.
High precision.
Water proof.
Assemble the fuse and thermostat in one product.
ltem NO | ELTH-001 8413A |
Use | Defrost/Temperature control/Protection |
Appliance | Refrigerators, Freezer |
Reset type | Automatic |
Basic material | Bakelite, Epoxy Resin, PA |
Electric rating | 250V 10A |
Action temperature range | -30°C~90°C |
Differential | According to the requirement |
Insulation resistance | ≥100MΩ |
Tolerance | Refer to the regulation |
Life cycle | 100,000 times |
Contact material | Silver |
Dielectric Strength | Parts between electriferous components and non-electriferous ones can bear 2000V (3750V for Reinforced insulation type) 50Hz AC current, which is nearly sine wave, for one minute as bearing test. Resulted no breakdown, no flashover. |
Insulation Resistance | With a DC 500V megger, borne DC 500V, the tested value is over 10MW. |
Resistance Between Terminals | Below 50mW |
Temperature characteristics | Normal close, Normal open |
Maximum Ambient Temperature | 90°C |
Diameter of Bimetal Disc | F12.7mm(1/2″) |
Wire Leads | Color: Red Length: customized |
Terminal type | Customized (Refer to our specification) |
Cover/Bracket | Customized (Refer to our specification) |
Sample Price | Free sample USD 50 freight charge, refund after mass order |
What happens when a defrost sensor goes bad?
Replace the refrigerator defrost sensor
When the defrost sensor trips, it shut off power to the defrost heater. If the defrost sensor trips because it's not working correctly, frost builds up on the evaporator fins, eventually making the refrigerator and freezer not cool well. the fridge.
We know that our customers are the foundation of our existence, so we insist on helping them maximize their value with high-quality Tooling Maker Customized Thermostat Shell Component Plastic Injection Mould and Molding and services. The company's operators and employees have always flattered the business tenet of pragmatism, innovation, and credibility, and forged corporate individual brands. The company has cultivated a professional team with rich experience in property asset management. It has formed a complete operating system in environmental management, customer service, project management, security and risk management, energy management and sustainable development, and has accumulated relatively Rich experience in the operation and management of high-level and super high-level commercial projects.
Hot Tags: refrigerator defrost thermostat replaces, suppliers, manufacturers, factory, customized, wholesale, bulk, in stock, free sample, washing machine control panel, Whirlpool Genuine Refrigerator Defrost Thermostat, Electronic Refrigerator Control Board, ksd defrost thermostat, bimetal thermostat, Washing Machine Computer Board
