The defrost thermostat is located near the defrost heater and is wired in series. It is usually located at the back of a side-by-side freezer or under the floor of a top freezer. It will be necessary to remove obstructions such as the contents of the freezer, freezer shelves, icemaker, and the inside rear or bottom panel of the freezer.
ltem NO | HB024 24347 |
Use | Defrost/Temperature control/Protection |
Appliance | Refrigerators, Freezer |
Reset type | Automatic |
Basic material | Bakelite, Epoxy Resin, PA |
Electric rating | 250V 10A |
Action temperature range | -30°C~90°C |
Differential | According to the requirement |
Insulation resistance | ≥100MΩ |
Tolerance | Refer to the regulation |
Life cycle | 100,000 times |
Contact material | Silver |
Dielectric Strength | Parts between electriferous components and non-electriferous ones can bear 2000V (3750V for Reinforced insulation type) 50Hz AC current, which is nearly sine wave, for one minute as bearing test. Resulted no breakdown, no flashover. |
Insulation Resistance | With a DC 500V megger, borne DC 500V, the tested value is over 10MW. |
Resistance Between Terminals | Below 50mW |
Temperature characteristics | Normal close, Normal open |
Maximum Ambient Temperature | 90°C |
Diameter of Bimetal Disc | F12.7mm(1/2″) |
Wire Leads | Color: Red Length: customized |
Terminal type | Customized (Refer to our specification) |
Cover/Bracket | Customized (Refer to our specification) |
Sample Price | Free sample USD 50 freight charge, refund after mass order |
What does defrost thermostat do?
Temperature – the defrost thermostat measures the temperature of the evaporator, activating once it reaches a set point to warm and defrost the evaporator. Frost thickness – an infrared sensor is used to measure how much frost built up and activate the heating element once it reaches a certain thickness.
