EASY TO INSTALL: It is made exactly fit for most top name brands (Whirlpool, Kenmore, KitchenAid, Maytag), and replaces part numbers: PL002 23437.
PREMIUM QUALITY: The replacement part is made from durable high-quality material and well-tested by the manufacturerMeet OEM standards - Ensure long-lasting and effective operation. The function of the defrost bi-metal thermostat is to clip onto the evaporator and protect your evaporator from overheating during the defrost cycle. This part fixes the following symptoms: Fridge too warm | Freezer not defrosting | Freezer section too warm | Fridge too cold.
SAVE TIME AND SAVE MONEY: Inexpensive way to fix or repair a refrigerator. If your refrigerator does not defrost properly you can test both the thermostat and the heater to figure out which part is at fault. For this repair, you will need a Phillips screwdriver, a 1/4 inch nut driver, a flat blade screwdriver, a pair of wire strippers, a roll of electrical tape, and a few butt splice connectors.
ltem NO | PL002 23437 |
Use | Defrost/Temperature control/Protection |
Appliance | Refrigerators, Freezer |
Reset type | Automatic |
Basic material | Bakelite |
Electric rating | 250V 10A |
Action temperature range | -30°C~90°C |
Differential | According to the requirement |
Insulation resistance | ≥100MΩ |
Tolerance | Refer to the regulation |
Life cycle | 100,000 times |
Contact material | Silver |
Dielectric Strength | Parts between electriferous components and non-electriferous ones can bear 2000V (3750V for Reinforced insulation type) 50Hz AC |
Insulation Resistance | With a DC 500V megger, borne DC 500V, the tested value is over 10MW. |
Resistance Between Terminals | Below 50mW |
Temperature characteristics | Normal close, Normal open |
Maximum Ambient Temperature | 90°C |
Diameter of Bimetal Disc | F12.8mm(1/2″) |
Wire Leads | Color: Red Length: customized |
Terminal type | Customized (Refer to our specification) |
Cover/Bracket | Customized (Refer to our specification) |
Sample Price | Free sample USD 50 freight charge, refund after mass order |
What does the bimetal thermostat do?
Bimetal Thermostats, which regulate the temperature inside heating pads, blankets, and medical pads, are used in any case where the applications need control for a low temperature. Bimetal Thermostats use two different kinds of metal to regulate the temperature setting.】
